MPC5200B Users Guide, Rev. 1
2-36 Freescale Semiconductor
Pinout Tables
Pin PSC2_3 Ball B08
GPIO hi - z GPIO
Simple General Purpose I/O
CAN1, CAN2 hi - z CAN2_RX
CAN Receive Data
AC97_2 hi - z AC97_2_BITCLK
AC97 Bit Clock
UART2 hi - z UART2_CTS
UART Clear To Send
UART2e hi - z UART2e_CTS
UARTe Clear To Send
CODEC2 hi - z CODEC2_CLK
CODEC Bit Clock
Pin PSC2_4 Ball A08
GPIO hi - z GPIO
Simple General Purpose I/O with WAKE UP
CAN1, CAN2 hi - z GPIO
Simple General Purpose I/O with WAKE UP
AC97_2 hi - z AC97_2_RES
AC97 Reset
UART2 hi - z GPIO
Simple General Purpose I/O with WAKE UP
UART2e hi - z UART2e_DCD
UARTe Carrier Detect
CODEC2 hi - z CODEC2_FRAME
CODEC Frame
Table 2-12. PSC2 Functions by Pin (continued)
PIN / BALL NUMBER Function
Reset
Value
Description
