Pinout Tables
PSC2_4 A08 USB_6 G04
PSC3_0 C07 USB_7 F01
PSC3_1 B07 USB_8 F02
PSC3_2 A07 USB_9 F03
PSC3_3 C06 VDD_CORE D05
PSC3_4 B06 VSS_IO/CORE J12
VDD_CORE D10 VSS_IO/CORE K10
VDD_CORE D11 VSS_IO/CORE K10
VDD_CORE K04 VSS_IO/CORE K11
VDD_CORE M04 VSS_IO/CORE K12
VDD_CORE P04 VSS_IO/CORE L09
VDD_CORE U07 VSS_IO/CORE L10
VDD_CORE U12 VSS_IO/CORE L11
VDD_CORE U15 VSS_IO/CORE L12
VDD_IO D06 VSS_IO/CORE M09
VDD_IO D09 VSS_IO/CORE M10
VDD_IO E04 VSS_IO/CORE M11
VDD_IO F04 VSS_IO/CORE M12
VDD_IO H4 VSS_IO/CORE U04
VDD_IO T4 VSS_IO/CORE U17
VDD_IO U05 VDD_CORE D07
VDD_IO U06
VDD_IO U09
VDD_IO U10
VDD_IO U13
VDD_IO U16
VDD_MEM_IO D12
VDD_MEM_IO D13
VDD_MEM_IO D15
VDD_MEM_IO D17
VDD_MEM_IO E17
VDD_MEM_IO F17
VDD_MEM_IO H17
VDD_MEM_IO K17
VDD_MEM_IO M17
Table 2-2. Signals by Signal Name (continued)
Signal Name Ball/Pin Signal Name Ball/Pin
