4 Chapter
4–1
Inspection Configuration
The CVIM2 system can be configured to perform a single inspection or
multiple related inspections. Each inspection involves the selection of
parameters that define the inspection sequence, the I/O interface, camera
usage, and communication messages. These parameters are stored in various
files that are referred to collectively as a configuration. A configuration file
is used to link all of the parameter files required for the single inspection or
multiple related inspections. Figure 4.1 illustrates the relationship between a
configuration file and the tool, discrete I/O, acquisition, and communication
files.
Figure 4.1 Configuration File Organization
Tool 1 parameters
Tool 2 parameters
. . .
Tool N parameters
Tools File #1
Tool 1 parameters
Tool 2 parameters
. . .
Tool N parameters
Tools File #6
Environment
Inspection name
Archive name
Inspection settings
Display settings
Inspection name
Archive name
Inspection settings
Display settings
Configuration File #1
Toolset 1
Toolset 6
Discrete I/O File Name
Module I/O assignments
System I/O assignments
Remote I/O assignments
LED assignments
Acquisition File Name
System settings
Line settings
Camera settings
Trigger settings
Message File Name
Message 1 settings
Message 2 settings
. . .
Message N settings
Configuration File #2 Configuration File #3
Acquisition File
Discrete I/O File
Message File
On–line memory
etc.
Config. filename
