5 Chapter Chapter 7
Inspection Tools
7–5
•
Feature A, Feature B –– The buttons accesses the “feature,” or
edge selection panels for the respective features. This function is
accessible only for certain gage operations.
•
Ranges –– The button accesses the range–selection panel, which
defines limits for gage inspection results.
•
Done –– When you pick the button, the system exits back to the
toolset edit panel.
A gage can be selected when the toolset edit panel is on the screen. Starting
from the main menu bar, the selection path to this panel is as follows:
Editors
→ Configuration → Setup → Tools. This selection path is shown
by the example in Figure 7.1 (page 7–2).
Here is a summary list of the basic gage selection and configuration steps,
listed in their normal order of performance. These steps are common to all
gage operations (except as noted):
1. Select gage operation.
2. Select the gage shape.
3. Select gaging mode.
4. “Pick and place” the gage.
5. Adjust edge detection parameters.
6. Select the width, filter, and threshold.
7. Learn nominal value.
8. Select ranges.
Each of the gages can be configured as a line gage, an arc gage, or a circle
gage, according to the requirements of your application.
When configuring a gage, the gage shape should be your first selection.
•
Line gage –– A line gage is defined by two points. You can place it
anywhere within the image and set it to any length and any angle.
•
Arc gage –– An arc gage is defined by a center point, a radius, a starting
angle, and an ending angle. You can place it anywhere within the image
and set it to any radius and any degree of arc.
•
Circle gage –– A circle gage is defined by a center point and a radius.
You can place it anywhere within the image and set it to any radius.
Overview: Gage
Configuration
Gage Shape
