Chapter 4
Inspection Configuration
4–20
Here is a brief description of each field in the Results display setup panel:
•
Title –– This field enables the user to select an appropriate name or “title”
for the results display panel that corresponds to the currently selected
toolset. By default, the initial title is “
Results ” plus the position number
of the toolset in the Configuration Editor panel. Thus, the default titles
of the results panels for toolsets #1, #3, and #6 would be Results 1 ,
Results 3 , and Results 6 , respectively.
•
Panel Position –– This parameter reflects the X– and Y–axis coordinates
of the upper–left and lower–right corners, respectively, of the results
display panel for currently selected toolset in the
Configuration Editor
panel (as illustrated in Figure 4.15 on page 4–22). When you pick the
Panel Position field, the results display panel for the selected toolset
appears on the screen, and is is accessible for resizing and repositioning
on the screen. (The image and results display panels for other toolsets are
also available at this time; however, they may appear on the screen as
icons.)
•
Start Iconized ? –– This parameter determines whether online operations
begin with the results display panel on the screen (“
No ”), or with an icon
representing the panel appearing at the right side of the screen (“ Yes ”).
The default selection is “ No .”
Setting Up Inspection Tools
NOTE: This section covers only the general configuration procedures. For
detailed information about the inspection tool types and tool operations, refer
to Chapter 7, Inspection Tools.
Assuming that the Configuration Editor panel contains the “ Toolset 1 ,”
“ Toolset 2 ,” and “ Toolset 3 ” inspections (as shown in Figure 4.7 on page
4–9), continue the configuration procedure with the following steps:
1. If you want to change the archive name “ EE:FrontLabel.ts1 ” to some
other name, pick the field containing the EE:FrontLabel.ts1 name.
When you do, the File Select panel appears on the screen, as shown in
Figure 4.14 (page 4–21).
Pick the button to access the keyboard. Enter the new archive
name, then pick the key to save the name, exit the keyboard, and
return to the File Select panel. Pick the button to exit back to the
Configuration Editor panel.
2. The small arrow (
→) alongside the toolset number indicates which
toolset is currently selected. Pick “1” to select the first toolset.
