This section discusses the expanded inspection results that are available to a
math tool formula from a build reference tool. As Figure 6.67 shows, the
expanded inspection results for a build reference tool appear in one list.
Figure 6.67 Expanded Results Lists For Build Reference Tools in Math Formulas
Execute
Pass
Warn
Fail
Total
Faults
X
Y
Theta
nX
nY
nTheta
Xc
Yc
Here is a brief definition and explanation of each of the expanded result
types listed in Figure 6.67 (page 6–78).
•
Execute –– This returns a 1.000 when the tool has executed its inspection
task, and 0.000 for all other conditions.
•
Pass –– This returns a 1.000 when the tool has passed its inspection task,
and 0.000 for all other conditions.
•
Warn –– For reference tools, Warn always returns 0.000 .
•
Fail –– This returns a “error code” when the tool is in a fail condition and
0.000 for all other conditions. The error code identifies a specific reason
for the failure; for example, error code 1049.000 identifies “Could not
access result” as the cause of the inspection failure. The complete list of
error codes and fail conditions appears in Appendix A of this manual.
•
Total –– This returns the total number of inspections performed.
•
Faults –– This returns the total number of faults detected.
•
X –– This returns the current value of the X result from the X Formula in
the build reference tool. (It is 0.000 if the X Mode is Enabled , but has
no usable X Formula , or it is Disabled .)
•
Y –– This returns the current value of the Y result from the Y Formula in
the build reference tool. (It is 0.000 if the Y Mode is Enabled , but has
no usable Y Formula , or it is Disabled .)
