Index
I–2
Basic steps, 3–16
Image setup, 3–17
Offset selections, 3–22
Pick and place, 3–21
Threshold adjustments, 3–22
Typical applications, 3–16
Calibrate panel, 3–19
Calibrate parameters
Calibration modes, 3–18, 3–19
Absolute, 3–19
Computed, 3–19
Dimensions, 3–18
Entering scale value, 3–25
Gage mode, 3–18
Binary, 3–20
Gray scale, 3–20
Gage width, 3–18
Scale, 3–19
Scale computation, 3–23
Units, 3–19, 3–23
Camera setup panel, 3–2
Camera type
Edit panel, 3–3, 3–33
Parameters
Acq. Center, 3–42
Acq. Lines, 3–38
Acq. Phase, 3–35
Acq. Pixels, 3–34
Acq. Start, 3–38
H.Scan Mode, 3–41
HD Length, 3–42
Int.End, 3–43
Int.Start, 3–43
Period, 3–42
Reset/Delay Mode, 3–41
Restore Length, 3–42
Restore Start, 3–42
Total (1/2 Lines), 3–43
Total (Pixels), 3–42
Transfer, 3–42
V.Scan Mode, 3–41
VD Length, 3–43
Selection, 3–4
Selection list, 3–3, 3–33
Change password, 12–5
Circularity, 7–36, 7–47
Communication port setup
Enable/disable discrete I/O, 10–11
Forces, 10–12
Outputs, 10–12
PLC test, 10–12
Remote I/O serial port
Data rate, 10–11
Rack address, 10–11
RS–232 serial port, 10–10
ASCII protocol, 10–10
DF1 protocol, 10–10
Keyboard (external), 10–10
Mouse, 10–10
Component list, CVIM2 System, 1–1
Conditional processing
Conditions panel, 7–183
Definition, 7–183
Inputs In1 – In4, 7–183
Invert function, 7–184
Config File panel, 2–3, 4–2
Configuration
Basic phases, 2–2
Basic procedure, 4–9
File names, 2–3, 4–3
Process, 4–2
Toolsets, 2–4
Configuration Editor panel, 2–4, 4–6
Archive name, 4–7, 4–8
Default, 4–11
Inspection name, 4–7, 4–8
Default, 4–10
Selection, 4–9
Purpose of, 4–6
Configuration file
Contents of, 4–3
Creation of, 4–2
Definition of, 2–3
Organization, 4–1
Configuration file selection, 10–2
Configuration parameters, 2–4
Contour Options panel, 7–35, 7–40
D
Destination buffers, 4–28, 4–30
Discrete I/O, File names, 4–3
Discrete I/O assignments, 9–1
Relation to configuration file, 9–3
Discrete I/O Editor panel, 2–7
+/– selections
Input signals, 9–13
Output signals, 9–14
