5 Chapter Chapter 4
Inspection Configuration
4–17
•
Pause Time –– This parameter sets the amount of time that the online
camera image pauses after a reject condition when the “pause” freeze
mode has been selected. The allowable range is 1 to 30 seconds. The
default time is 5 seconds.
•
Reject Queue –– This parameter sets the number of extra image buffers
allocated to save “rejected” images during freeze mode operation. For
most applications, a setting of 0 enables the CVIM2 system to save one
rejected image, while a setting of 1 enables the system to save one
additional rejected image. For some very high speed applications, a
setting of 1 may be required to guarantee that the first rejected image is
saved. For details about the freeze mode operations, refer to Chapter 10,
Environment Menu Selections, under the Display heading on page 10–16.
•
Register (Setup) –– This parameter selects the default state of the register
function in the toolset edit panel. “
Yes ” causes the function to be active
whenever the toolset edit panel is accessed during setup operations, while
“
No ” has the opposite effect.
•
Display All (Setup) –– This parameter selects the default state of the
display function in the toolset edit panel. “
Yes ” causes the function to be
active whenever the toolset edit panel is accessed during setup operations,
while “
No ” has the opposite effect.
•
Num Image Panels –– This parameter selects the number of image
display panels that can appear during run operations for the currently
selected toolset. Each camera being used in the toolset can have an
associated image display panel. The default value is 1, and the valid range
is 1 – 3.
•
Camera 1, 4 Angle –– This parameter can be set to rotate the camera #1
and #4 image field and tool graphics clockwise by 90
°, 180°, or 270°.
•
Camera 2, 5 Angle –– This parameter can be set to rotate the camera #2
and #5 image field and tool graphics clockwise by 90
°, 180°, or 270°.
•
Camera 3, 6 Angle –– This parameter can be set to rotate the camera #3
and #6 image field and tool graphics clockwise by 90
°, 180°, or 270°.
NOTE: The camera angle settings will affect the image field in the
image display panel only when it is displaying inspection results. The
image field will appear in its normal, non–rotated orientation during tool
configuration.
Here is a brief description of each button in the Display panel:
•
Image 1, 2, 3 –– Use the , , or button to select the
image display setup panel for the currently selected toolset. When you
pick one of the active (not shaded) buttons, a corresponding image
display setup panel appears. By default, the
button is active and
the and buttons are shaded.
The value in the Num Image Panels field of the Display panel
determines which buttons are active (since “1” is the lowest number, the
button is always active). Entering a “2” in the Num Image
Panels field of the Display panel activates the button, while
entering a “3” activates both the and the buttons.
