Appendix B

Environment Variables

B–2

Name

Usage

Maximum

Minimum

Default

ББББ

Lang

ББББ

Eng

ББББ

n/a

ББББ

n/a

БББББББББББ

Б ББББББББББ

БББББББББББ

Specifies the current language for the CVIM2
menus. THIS VARIABLE SHOULD BE CON-
FIGURED USING THE LANGUAGE MENU
OPTION UNDER ENVIRONMENT. IT
SHOULD NOT BE MODIFIED!

ББББ

golm

ББББ

350000

bytes

ББББ

32K bytes

ББББ

400K bytes

БББББББББББ

Б ББББББББББ

БББББББББББ

Specifies the amount of graphics memory
available for configuration. DO NOT USE
WITHOUT CONSULTING AN
ALLEN–BRADLEY REPRESENTATIVE!
Usage: golm=350000

ББББ

mmol

ББББ

N/A

ББББ

N/A

ББББ

N/A

БББББББББББ

Not used in firmware revision B03 and higher.

ББББ

olm

ББББ

280000

bytes

ББББ

32K bytes

ББББ

280K bytes

БББББББББББ

Б ББББББББББ

БББББББББББ

Specifies the amount of memory available for
contour, configuration and results data. DO
NOT USE WITHOUT CONSULTING AN
ALLEN–BRADLEY REPRESENTATIVE!
Usage: olm=280000

ББББ

norun

ББББ

n/a

ББББ

n/a

ББББ

n/a

БББББББББББ

Б ББББББББББ

БББББББББББ

If present, the CVIM2 system will not auto-
matically enter run–mode after power–up ini-
tialization.
Usage: norun

ББББ

oldpipe

ББББ

n/a

ББББ

n/a

ББББ

n/a

БББББББББББ

Б ББББББББББ

БББББББББББ

If present, the CVIM2 system may interrupt
image processing to display an image in its
entirety. When not present, the CVIM2 will
interrupt image displays to perform inspec-
tions which may cause the image display to
appear in phases. DO NOT USE WITHOUT
CONSULTING AN ALLEN–BRADLEY REP-
RESENTATIVE!
Usage: oldpipe

ББББ

porta
portb
portc
portd

ББББ

n/a

ББББ

n/a

ББББ

n/a

БББББББББББ

Б ББББББББББ

БББББББББББ

Specifies the configuration of the four serial
ports. Ports C and D refer to the System I/O
port. THESE VARIABLES SHOULD BE CON-
FIGURED USING THE SERIAL PORT CON-
FIGURATION MENU. THEY SHOULD NOT
BE MODIFIED!

ББББ

ramdev-

size

ББББ

4K bytes

ББББ

4K bytes

ББББ

128K bytes

БББББББББББ

Б ББББББББББ

БББББББББББ

Specifies the amount of system RAM to re-
serve for the RM: device. This memory device
is volatile and should not be used for perma-
nent file storage. It is used by some optional
CVIM2 software packages and for temporary
file storage when processing ”toolcfg” com-
munication commands. The size should only
be increases when the ”toolcfg” command
needs additional space to store temporary
files.
Usage: ramdevsize=4096

ББББ

Resources

ББББ

n/a

ББББ

n/a

ББББ

n/a

БББББББББББ

Б ББББББББББ

БББББББББББ

If present, the Main Menu will contain a menu
option to access the system Resources pan-
el. This includes memory usage, and CPU/
Pipe utilization meter.
Usage: Resources
