NOTE: In the following discussions, the use of a mouse is assumed for the
screen pointer functions. Table 2.1 compares equivalent light pen and mouse
operation.

Figure 2.10 through Figure 2.12 (page 2–13) illustrate the screen pointer
functions.

Figure 2.10 demonstrates a sequence of menu item and button picks, starting
at “

Editor

” in the main menu bar. In this figure, the pointer is positioned over

Editor

in the main menu bar, and the left button is clicked, in order to select

the

Editor

menu. The pointer is then positioned over

Configuration

in the

Editor

menu, and the left button is clicked, in order to select the

Configuration Editor

panel.

Figure 2.10 Example:

Sequence of Menu and Panel Selections

ЗЗЗЗ

Pick

ЗЗЗ

ЗЗЗЗ

ЗЗЗ

Pick
