Chapter 11
File Functions
11–10
Figure 11.8 Example: Delete Warning Message Box
If you intend to perform the delete function, pick the button; if not, pick
the button to exit the delete function.
If you pick the button, the file whose name appears in the warning
message box will be deleted. If two or more files were highlighted in the file
listing, a warning message will appear for each highlighted file. Thus, a
“Yes” or “No” decision must be made for each of these files.
Battery Change
The battery change function enables you to change the battery in a memory
card while the card is inserted in the CVIM2 module front panel slot. The
battery should be changed whenever the battery status message (on the
File
panel) indicates that the battery is low, or every two years, as a preventive
measure.
The button becomes active when you highlight “ MC ” in the device
list. When you pick the button, the CVIM2 module applies power to
the memory card and turns on the Memory Active LED, which indicates that
you can remove the battery without losing data. Also, a warning message box
appears on the screen, as shown in Figure 11.9.
Figure 11.9 Example: Battery Warning Message Box
To perform the battery change function, follow the instructions in the
message box, then pick the
button when the change is completed.
