Table 1-6: IP Core FPGA Resource Utilization in Arria 10 Devices
Lists the resources and expected performance for selected variations of the Low Latency 40-100GbE IP cores in an
Arria 10 device.
These results were obtained using the Quartus II v14.1 software.
• The numbers of ALMs and logic registers are rounded up to the nearest 100.
• The numbers of ALMs, before rounding, are the ALMs needed numbers from the Quartus II Fitter Report.
40GbE Variation ALMs Dedicated Logic
Registers
Memory
M20K
40GbE variation A
5400 12800 13
40GbE variation B
10100 21200 13
40GbE variation C 11000 24100 13
40GbE variation D
14200 31100 17
40GbE variation E
14400 28200 26
40GbE variation F 16300 29300 26
100GbE Variation ALMs Dedicated Logic
Registers
Memory
M20K
100GbE variation A
13100 29000 29
100GbE variation B
21200 47600 61
100GbE variation C 22500 51800 61
100GbE variation D
27000 63200 65
CAUI-4 Variation ALMs Dedicated Logic
Registers
Memory
M20K
CAUI-4 variation B
22700 51300 61
Related Information
Fitter Resources Reports in the Quartus II Help
Information about Quartus II resource utilization reporting, including ALMs needed.
