Hardware Output Resources
You create Channels, Readouts, Digital Outputs, and Calculated Outputs (station resources in the navigation
pane) by selecting resources in the associated Output Hardware Resources lists.
Description Example Resource type
Valve drivers are internal electronic modules that control
servovalves. 493.14 2SVD S3-J4
493.15 3SVD S3-J5
Valve Drivers
You can used valve driver resources to create Channels
and Calculated Outputs.
494.16 2SVD S5-J1B
494.16 3SVD S5-J1A
Analog outputs are connectors located on the chassis rear
panel. Analog output resources can be used to send 494.41 D/A 1
493.46 D/A 1 S6-J13
D/A Outputs
commands to an external valve driver or external controller
494.46 D/A 1 S4-J3A (±10 volts output), or to make controller signals available
for monitoring by external readout devices, such as scope
and meters.
Wago D/A 1-1
Monitor 1 (Model 493.42
System I/O board)
You can use analog output resources to create Channels,
Readouts, and Calculated Outputs.
Anlg Out (Model 493.42
System I/O board)
You can use digital output resources to create Digital
Outputs. 493.72 DO T1-J4
Wago DO 1-1
Digital Outputs
Dig Out 1 (Model 493.42
and Model 494.41 and
Model 494.44 System I/O
boards)
You can use temperature control resources to create
Channels and Calculated Outputs. Temp Control 1-1 Output Temperature Control
Calculated outputs are values generated by user-defined
algebraic formulas. <> Calculated Output
You can use calculated output resources to create
Channels, Digital Outputs, and Calculated Outputs.
Hardware Input Resources
You create Channels, Readouts, Digital Inputs, and Calculated Inputs (station resources in the navigation
pane) by selecting resources in the associated Input Hardware Resources.
Description Examples Resource Type
Digital universal conditioners are internal electronic modules
that condition transducer output. 493.21 DUC S3-J5
493.21B DUC S3-J7
Digital Universal
Conditioners
(DUC)
