Description Item
Normal—A clockwise knob movement typically extends the actuator. Polarity
Invert—A clockwise knob movement typically extends the actuator.
5. In addition to the Remote Setpoint Knob settings listed above, there is a Remote Setpoint Adjust station
control that you can use to assign channel, and control modes to each knob, and to set up password
access to RSA disable.
UPS Options
Uninterruptable Power Supply (UPS) Settings
This window allows you to select actions related to an uninterruptable power supply (UPS). If line power fails
and the UPS supplies power to the system, a message is written to the Message Log. When line power is
resumed, another message is written to the Message Log.
Note:
The Station UPS Options window is available only if the UPS option is enabled in the associated
hardware interface file (hwi). For more information, see the Hwi File Editor section of the MTS Series
793 Utility Software manual (part number 100-147-132).
Note:
Requires Configuration access level to adjust
Access
Station Setup window > navigation pane > Station UPS.
Reset
Click Reset on the Station Controls Panel.
• If the UPS event that caused the action returns to normal, any action assigned to that event is reset and
returned to the normal (untripped) state.
• If the UPS event that caused the action is still true, any action assigned to that event will occur again.
Station UPS Options window
Description Item
Select an action to occur if line power fails and the UPS supplies power to the system. On UPS Actions
Select the amount of time (in seconds) that the UPS can supply power to the system
before the action selected for the On UPS Delay Actions control is executed. On UPS Delay
