4 Setting up the DSD workplace
4.5 Settings
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.5.6 "Protocol" tab
4.5.7 "Customer data" tab
Customer data is managed in the DSD in a customer database. In the "Login" dimensioning step you
select customer data or set up new customers. Using the export and import, you can transfer the
customer data to other DSD installations.
Settings Information
Output format Setting of the output format for the log file:
• Word 97-2003 document (*.doc)
• Microsoft Word 97 to Word 2003
• Word document (*.docx)
• From Microsoft Word 2007
• Portable document format (*.pdf)
• PDF (for reading the file, Adobe Reader is required.
Preferences for the detailed protocol
Settings for the commissioning data
The two tabs can be used to make separate settings for the detailed protocol
and the commissioning data.
Output of
Selection of additional information which is to contain the detailed Protocol
and the commissioning data
• Notes
• Notes for single dimensioning steps written by the user.
• Diagrams
• Dependent on the settings under Detailed selection diagrams/table of
values.
• Tables of values
• Dependent on the settings under Detailed selection diagrams/table of
values.
• Product options
• Details on Lenze products like motor, brake, gearbox, inverter.
Detailed selection diagrams/tables of values
Selection of diagrams and tables of values which are to contain the detailed
Protocol and the commissioning data.
• Extensive selection of diagrams and tables of values regarding applica-
tion, gearbox, motor, inverter, DC bus and energy efficiency on evaluating
and analysing the dimensioning.
Lenze setting The selection of diagrams and tables of values is reset to the Lenze setting.
Settings Information
Export Export of the complete customer data to an XML file.
Import Import of the XML file with customer data.
