8.2.9.19
Specification – jerk
8.2.9.20
Left – jerk
8.2.9.21
Middle – jerk
8.2.9.22
Right – jerk
8.2.9.23
Jerk ratio – jerk
8.2.9.24
S-ramp time – jerk
Parameter
Description
Specification
The following quantities can be selected:
• Jerk ratio:
• Percentage of the three sections "Show", "Linear acceleration" and "Hide" in the entire
element.
• S-ramp time:
• Duration of the show and hide phase.
• Jerk:
• Acceleration during the show and hide phase.
• Max. acceleration
• Acceleration or deceleration from start to end of the element operation.
• The selection is only shown for an S-shaped element.
Parameter
Description
Left
Jerk for the acceleration from standstill to setpoint speed.
Parameter
Description
Centre
Jerk for further acceleration or deceleration.
• The input field is only shown in case of an element for creep speed.
Parameter
Description
Right
Jerk for the deceleration to standstill.
Parameter
Description
Jerk ratio
Percentage of the three sections "Show", "Linear acceleration" and "Hide" in the entire ele-
ment.
Parameter
Description
S-ramp time
Duration of the show and hide phase.
