9 Mains and environment
9.2 Ambient conditions
280
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.2.3 Site altitude
The components can be operated up to a site altitude of 1000 m amsl without power reduction.
• From 1000 ... 4000 m amsl there is a power reduction.
• For inverters the derating factor is stored in the DSD device-specifically.
• The site altitude for geared motors is considered as a function of the temperature:
• For motors without a gearbox, the following applies:
ϑ
opr
k
h
≤ 1000 m ≤ 2000 m ≤ 3000 m ≤ 4000 m
20 °C 1.15 1.04 0.92 0.81
30 °C 1 0.9 0.8 0.70
40 °C 0.8 0.72 0.64 0.56
50 °C 0.6 0.54 0.48 0.42
60 °C 0.4 0.36 0.32 0.28
h k
h
0 ... 1000 m 1
≤ 2000 m 0.95
≤ 3000 m 0.9
≤ 4000 m 0.85
