16 Auxiliary means
16.1 Auxiliary means integrated in the DSD
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
16.1.1.8 "Uniform load mass (material handling technology)" calculator

How to call the calculator:
• Via the ToolsSpecial auxiliary calculatorsUniform load mass (material handling
technology)... command
• Via the icon in the input area.
The calculator serves to calculate the length of expanded loads.

Tip!
For belt applications, the
"Mass of belt" calculator is provided. ( 417)
Button Function
= Calculate result.
Close Close dialog box.
• Only available if the calculator is called via the menu bar.
Accept Accept calculated value for the parameter and close dialog box.
• Only available if the calculator is called via the input area.
Cancel Discard calculated value and close dialog box.
• Only available if the calculator is called via the input area.
Input field Meaning
Weight per length Input parameters for the calculation
Conveying length

Note!
The DSD does not transfer values from the input area to the auxiliary calculator.
• Ensure that the value for the conveying length in the auxiliary calculator corresponds
to the value entered in DSD to avoid incorrect calculations.
