Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
227
8 Motion design
8.2 MotionDesigner
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.2 Toolbar
Click on an icon to carry out the respective function.
Symbol Keyboard com-
mand
Function
+ Create new motion profile.
+ Load motion profile.
 Load the motion profile ( 234)
+ Save motion profile.
• When a newly created motion profile is saved, you are asked for the destina-
tion of the Imp file.
• When the motion profile is newly saved, the Imp file is updated.
 Save motion profile ( 235)
– Import the motion profile with parameter profiles from an ASCII file.
 Importing profile data ( 236)
– Create note for motion profile
• The note is attached to the "Motion" dimensioning step.
• The function is only available with the application-dependent MotionDesign-
er.
 Notes ( 37)
Delete highlighted element.
• The element is deleted permanently.
– Application analysis.
• Shows diagrams and table of values via the entered and calculated values
with regard to a cycle of the motion profile.
• The function is only available with the application-dependent MotionDesign-
er.
+ Undo last action.
+ Redo last undone action.
– Default settings for the dialog box.
• Identical to the "Motion" register in the DSD menu ExtrasSettings.
 Settings ( 46)
 "Motion" register ( 48)
– Zoom x-axis and y-axis
• Draw up a rectangle across the area to be zoomed in by keeping the left
mouse button pressed.
– Return to standard view.
+ Cut the highlighted element and drag to the clipboard.
+ Copy the highlighted element into the clipboard.
+ Paste the element from the clipboard.
– Select the element or deactivate an active symbol.
– Draw trapezoidal element.
• The "Profile" register contains a selection of trapezoidal elements.
 Creating and editing elements ( 242)
 Parameter area: Description ( 247)
