8 Motion design
8.2 MotionDesigner
228
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.3 Screen divider
By dragging the screen divider, the size of the Object area or the drawing area is changed horizon-
tally.

How to drag the screen divider:
1. Move the mouse pointer over the screen divider  until it is visible as two vertical lines.
2. Press the left mouse button and drag the screen divider.
3. Release the mouse button at the desired position.
– Draw line.
 Creating and editing elements ( 242)
– Draw S-shaped element.
 Creating and editing elements ( 242)
– Import an individual motion profile or parameter profile.
 Importing profile data ( 236)
– Move elements to the left.
• Moves separated elements on the drawing area to the left and connects them
to its preceding element.
 Shift elements automatically to the left ( 244)
– Combines the elements that form a trapezium so that an element is generated.
• Only connected elements can be combined.
• The elements to be combined must be highlighted.
 Combining elements ( 245)
– Undo combination.
• Deactivate the combination of a trapezoidal element so that the elements
can be processed separately.
– Reflect highlighted element on the time axis.
• This function can only be accessed via the context menu (click the left mouse
button).
– + Duplicates an element in the drawing area when the element is left-clicked
while the Ctrl key is pressed.
– + Shows or hides the grid of the drawing area.
– + Highlights all elements on the drawing area.
– + In order to highlight several elements keep the button pressed and left-
click the elements.
Symbol Keyboard com-
mand
Function
