8 Motion design
8.2 MotionDesigner
238
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.5.5 Error messages during import
Error message Causes, possible remedies
Error during import. The ASCII file cannot be read. Either it is defect or the
data does not have a valid format.
The imported file contains parameters which are not
available in the MotionDesigner. These parameters will
not be imported.
Check the motion profile with its parameters in the Mo-
tionDesigner.
Sequence and number of the parameters in the ASCII file
do not comply with the structure created in the Object
area of the MotionDesigner.
Either correct the ASCII file or adapt the structure in the
Object area.
Syntax error when evaluating the dimension units and
the columns in the header.
The DSD does not know a unit in the ASCII file or the se-
quence of the columns is mixed up.
Check the units in the ASCII file or correct the sequence
of the columns.
The imported values are outside the valid value range. The data in the ASCII file is not consistent. Examples: The
lines do not contain data, masses are negative, digital
signals do not have 0 or 1.
Error in line x The ASCII file contains a wrong character in the named
line. For instance, a decimal number contains a letter.
The imported file does not contain any data. The ASCII file does not contain any data.
The motion profile in the MotionDesigner contains pa-
rameters which do not appear in the file to be imported.
Check the motion profile including its parameters for
completeness in the MotionDesigner.
The ASCII file contains less information than the Mo-
tionDesigner is able to process for the drive dimension-
ing. The ASCII file does not contain any values for
individual tracks. These tracks are pre-assigned with ze-
ro.
Check ASCII file.
Error reading the file to be imported
or access error.
Another program accesses the ASCII file.
Syntax error when evaluating the imported data. The ASCII file contains wrong delimiters. Permitted are
semicolons, tabulators or spaces.
The ASCII file contains invalid characters. For instance, a
decimal number contains a letter.
The type of motion profile does not match the type spec-
ified in the imported file.
Instead of a translatory motion profile, a rotary one has
been imported or vice versa.
The motion profile to be imported must correspond to
the motion profile set in the MotionDesigner.
At least one dimension unit in the file to be imported is
unknown.
The import is aborted.
A unit in the ASCII file is unknown to the DSD.
Check the units in the ASCII file.
The imported values are not in ascending order. Arrange the values in the ASCII file in ascending order.
The temporal characteristic must have continuously as-
cending values.
Negative import values are not permissible for this pa-
rameter.
The track does not permit negative values (e.g. mass). En-
ter parameters with positive signs only.
The import values of a digital signal must be 0 or 1. The data in the ASCII file are not consistent.
Enter 0 or 1 for digital signals only.
The import values for the curve contain an impermissible
step change.
Values with step changes are not permitted for the track
(e.g. speed curve).
The import values for this parameter must be sectionally
constant (discrete).
For this track, quantities are not permitted that change
continuously (e.g. mass).
