8 Motion design
8.2 MotionDesigner
234
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.5 Managing motion profiles
The MotionDesigner provides three formats for the management of the motion profiles and param-
eters.
8.2.5.1 Load the motion profile

How to load a motion profile:
1. Click the icon in the toolbar.
2. In the Load motion profile dialog box, select a motion profile in the *.lmp format and acti-
vate the Open button.
• It is only possible to load motion profiles that have been saved in DSD.
• When the motion profile is loaded, it is checked whether the motion (translatory or ro-
tary) matches the application.
• If the motion profile contains working points with high values, the scaling in the Graphic
area is adapted automatically.
File extension Format Description
lmp Lenze Motion Profile The MotionDesigner saves and opens motion profiles in this
format.
• Created motion profiles are upwards compatible. They
can be opened with previous DSD versions. There is no
downward compatibility.
txt ASCII file The MotionDesigner can import or export motion profiles
and parameters in the txt format.
• It is possible to export CAM curve profiles in the txt for-
mat with the CamManager in the »Engineer«.
dpr Motion profile from a previous DSD version.
• Files in the dpr format can only be imported in the Mo-
tionDesigner.

Note!
• In the dimensioning-dependent MotionDesigner, you can only load motion profiles
that match the motion (translatory or rotary) of the application.
• In the independent MotionDesigner, comprehensive editing functions are available. In
the application-dependent MotionDesigner, the editing functions are limited.
• If you have created a motion profile with the independent MotionDesigner and
open it with the application-dependent MotionDesigner, all editing functions will
be available.
• If you have created a motion profile with the application-dependent MotionDesign-
er and open it with the independent MotionDesigner, the editing functions will be
limited.
