7 Applications
7.7 Wheel drive
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.7.2.5 Specific travelling resistance
VULKOLLAN wheels
VULKOLLAN wheels are particularly suitable for conveyors and drives for loads up to 10 t or even
more.
• For the determination of the travelling resistance the following table can be included:
• Usually the consideration of the rolling friction is sufficient with regard to determining the trav-
elling resistance. Only for applications featuring frequent start-stop processes, the travelling re-
sistance increases due to the starting resistance.
7.7.2.6 Velocity
7.7.2.7 Mass of the payload
Symbol Description
F’ Specific travelling resistance
• If the specific travelling resistance is calculated via the "travelling resistance" calculator, the
values for wheel diameter and angle of tilt must be entered in the calculator for this purpose.
"Travelling resistance" calculator ( 419)

Note!
VULKOLLAN is a registered trademark of BAYER AG.
Travelling resistance in % Travelling resistance in N/t
Rolling resistance at 20 °C
in % of load
0.8 to 0.9 80 to 90
Start-up resistance at 20 °C
in % of load
1.1 to 1.4 110 to 140
Symbol Description
v Velocity of the vehicle
• Value is entered in the Motion dimensioning step.
Symbol Description
m
L
Mass of the payload without the vehicle.
• Value is entered in the Motion dimensioning step.
