8 Motion design
8.2 MotionDesigner
232
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

ParameterHighlight the parameter, press the right mouse button and select Object proper-
ties from the context menu to open the Object properties dialog box.
Legend Description
 Parameter name.
• Click into the input field and enter a name for the parameter.
 Creating a parameter profile: Principles ( 240)
 Selection of the parameter.
• Click into the list field and select the desired parameter.
• Possible selection: Mass of payload, counterforce, moment of inertia, torque, brake, controller in-
hibit.
• The selection is only possible if the parameter has been created with the independent MotionDe-
signer.
 Selection of the line colour.
• The parameter profile is displayed in this colour on the drawing area in the background.
• Click the button to open the dialog box for selecting the desired colour.
 Graphic area ( 239)
 Display of the parameter profile in the background
• When you select other parameters, the motion profile remains visible on the drawing area in the
background.
 Graphic area ( 239)
Field activated: Motion profile is visible.
Field deactivated: Motion profile is invisible.
