7 Applications
7.22 Winding drive for rewinder/unwinder
220
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.22.7.4 Max. tensile force with d
min
(rewinder)
Generally, the operators of the plant know the optimal values for the tensile force range F
max
(d
min
)
to F
max
(d
max
) and also know about tensile force drops for rewinders, if any. They are familiar with
the technical winding process and the material to be wound and are experienced with these often
empirical data.
Chapter 5.10 of the "Drive solutions - formulae, dimensioning and tables" Lenze documentation
provides recommendations for tensile forces and the winding process. The values are based on
many years of experience from many winding applications implemented.
• Select the ToolsFormulary command to open the documentation as PDF.
7.22.7.5 Max. tensile force with d
max
(rewinder)
Generally, the operators of the plant know the optimal values for the tensile force range F
max
(d
min
)
to F
max
(d
max
) and also know about tensile force drops for rewinders, if any. They are familiar with
the technical winding process and the material to be wound and are experienced with these often
empirical data.
Chapter 5.10 of the "Drive solutions - formulae, dimensioning and tables" Lenze documentation
provides recommendations for tensile forces and the winding process. The values are based on
many years of experience from many winding applications implemented.
• Select the ToolsFormulary command to open the documentation as PDF.
7.22.7.6 Min. tensile force with d
min
(rewinder)
7.22.7.7 Max. tensile force with (unwinder)
7.22.7.8 Min. tensile force (unwinder)
Parameter Description
F
max
(d
min
) Max. tensile force with min. reel diameter.
Parameter Description
F
max
(d
max
) Max. tensile force with max. reel diameter.
Parameter Description
F
min
(d
min
) Min. tensile force with min. reel diameter.
Parameter Description
F
max
(d
max
) Max. tensile force with max. reel diameter.
Parameter Description
F
min
Min. tensile force of the winding drive
