16 Auxiliary means
16.1 Auxiliary means integrated in the DSD
422
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
16.1.1.13 "Leadscrew efficiency" calculator

How to call the calculator:
• Via the ToolsSpecial auxiliary calculatorsLeadscrew efficiency... command
• Via the icon in the input area.
The calculator serves to calculate the efficiency of the spindle of a spindle drive.
Button Function
= Calculate result.
Close Close dialog box.
• Only available if the calculator is called via the menu bar.
Accept Accept calculated value for the parameter and close dialog box.
• Only available if the calculator is called via the input area.
Cancel Discard calculated value and close dialog box.
• Only available if the calculator is called via the input area.
Input field Meaning
Leadscrew pitch Input parameters for the calculation
Effective (frictional)
leadscrew diameter
Coefficient of friction
of the leadscrew

Note!
The DSD does not transfer values from the input area to the auxiliary calculator.
