Lenze DSD - Manual (Page 47)

Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
47
4 Setting up the DSD workplace
4.5 Settings
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.5.1 "General" register
4.5.2 Register "Local area network"
4.5.3 "Help" tab
Settings Information
Working directory Selection of the directory that is called by default for opening and saving
projects.
• Use last path
• Defines whether the directory called last is used for opening and saving
projects.
Autosave Automatic saving of the open projects according to the time interval set.
Script Define the font used in the masks
Start-up window • Display start-up window
• Define whether the start-up window is to be displayed when starting
the DSD.
Tips for drive dimensioning • Display tips
• Tips contain useful information about optimising settings.
Main memory Reserve main memory (RAM) of the computer for DSD.
• The change of the setting requires a restart of the DSD.
• As long as DSD is open, the reserved main memory is not available for
other applications.
• Generally, the Lenze setting is sufficient.
• Reserve more main memory if
• many projects are open at the same time and are to be processed,
• a motion profile with a lot of grid points is to be imported into the
project.
Settings Information
Proxy server Activate Use proxy server for Internet connection if an Internet connection is
only possible via a proxy server in your local area network. A proxy acts as a
switching centre between your computer and the rest of the Internet.
• Ask your system administrator for the Address and the Port of the proxy
server.
Login • Ask your system administrator if you require a User name and a Password
for accessing the proxy server.
Settings Information
Language Language selection for the online help.
Selection of the language on the Lenze web page if a weblink is called.
