3 User interface
3.1 Control and function elements
38
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

How to open created notes:
Three options to open a single note:
• Click the desired notepad in the Navigation tree.
• Click the Create note button in the status bar.
• Select the desired dimensioning step in the Navigation tree and execute the command
ViewNotesNote of current dimensioning step.
Open the All notes dialog box:
• Select the desired dimensioning step in the Navigation tree and execute the command
ViewNotesAll notes.

How to delete notes:
A single note:
• Select the desired dimensioning step in the Navigation tree, open the Context menu with
the right mouse button and select Delete note.
All notes:
• Execute the command ViewNotesAll notes.
• Go to the All notes dialog box and press the Delete all button.
• Press OK to close the dialog box.

Note!
• You cannot change notes in the dialog box.
• Copying of texts is possible.
• You can print notes via the Print button.
