3.1.2 Toolbar
Via the icons in the toolbar you can directly carry out the most frequently used functions.
• Click on an icon to carry out the respective function.
Symbol Menu command Keyboard com-
mand
Function
File  New +  Create new project ( 52)
File  Open... +  Open project ( 54)
File  Save +  Saving the project ( 54)
Edit  Undo – Undo last action
Edit  Redo – Redo last undone action
View  Dimensioning report... –  Protocols ( 391)
View  Warning signals... – Shows all warning signals, notes and tips for
the current drive dimensioning.
 Drive dimensioning messages ( 441)
Tools  Calculator... –  Calculator (Microsoft® calculator) ( 404)
Tools  Inertial calculator...  Inertial calculator ( 407)
Tools  Mass calculator...  Mass calculator ( 405)
Tools  MotionDesigner... – Creating, changing and saving motion pro-
files
 MotionDesigner ( 225)
Tools  Energy-efficient fan/pump... – Detecting energy efficiency for applications
with fans or pumps
Tools  Gearbox calculator...  Gearbox calculator ( 410)
Tools  Application checklist... –  Data collection via checklists ( 55)
View  Project comparison... –  Project comparison ( 61)
Help  Help Call up help
– – Call up context-sensitive help
