Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
389
15 Results: comparing, optimising, logging
15.1 Drawing
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Editing functions
n
out,K
Output speed of the additional drive element
ω
Angular velocity
P Power, application, motor
P
DC
Required power in the DC bus
P
req
Required power
ϑ
%
Thermal utilisation
T
BRK
Theoretical braking time of the mechanical brake
• The time from the respective operating point until standstill is calculated
v Velocity
W
l/t
Characteristic of the gearbox fatique strength
E94APx Requirement calculation of the drive axis when the 9400 power supply module is used
E94ARx Requirement calculation of the drive axis when the 9400 regenerative power supply module is used
R Brake resistor
int.Chp Brake chopper integrated in the inverter
int.Chp 94 Brake chopper integrated in the 9400 power supply module or 9400 regenerative power supply
module
Function Description
Zooming • Zooming in:
• Draw up a rectangle across the area to be zoomed in by keeping the left mouse button pressed.
• Zooming out:
• Open the context menu with the right mouse button. There are three commands for zooming
out under Automatic adjustment.
Merge Open the context menu with the right mouse button. Execute the Merge command to copy the di-
agram to clipboard.
Save as... Open the context menu with the right mouse button. Execute the Save as... command to save the
diagram as PNG graphic (Portable Network Graphic).
Print... Open the context menu with the right mouse button. Execute the Print... command to open a dialog
box which serves to print the diagram.
Button Information
