8.2.9.8 Velocity (right) / speed (right) – basic values
8.2.9.9 Velocity / final speed – basic values
8.2.9.10 Starting velocity / starting speed – basic values
8.2.9.11 Acceleration – basic values
8.2.9.12 Left – basic values
Parameter Description
Velocity (right)
Speed (right)
• Translatory motion profile:
• Velocity after the second acceleration or deceleration.
• Rotary motion profile:
• Speed after the second acceleration or deceleration.
• The input field is only shown in case of an element for creep speed.
Use of the parameter:
 "Profile" tab ( 248)
Parameter Description
Velocity
Final speed
• Translatory motion profile:
• Velocity when the operation of the element is completed.
• Rotary motion profile:
• Speed when the operation of the element is completed.
Use of the parameter:
 "Line" tab: Motion profile ( 250)
 "S-edge" tab ( 253)
 "Imported profile" tab ( 254)
Parameter Description
Starting velocity
Starting speed
• Translatory motion profile:
• Velocity when the operation of the element starts.
• Rotary motion profile:
• Speed when the operation of the element starts.
• The input field is only shown if an element is selected.
 "Line" tab: Motion profile ( 250)
 "S-edge" tab ( 253)
 "Imported profile" tab ( 254)
Parameter Description
Acceleration Acceleration or deceleration from start to end of the element operation.
 "Line" tab: Motion profile ( 250)
Parameter Description
Left Value when the operation of the element starts.
 "Line" tab": Parameter profile ( 251)
