10.3.4 Inverter properties
In the subchapters, the inverters available in DSD are described. The tabular representation makes
it possible for you to easily compare the properties to each other.
10.3.4.1 Frequency inverter
Frequency inverters are suitable for simple, speed-controlled drive tasks, and they are cost-effective.
A speed feedback is not necessarily required.
8400 BaseLine 8400 StateLine 8400 HighLine
Illustration
Short description Frequency inverters with integrated
keypad, V/f control and sensorless
vector control, overload capacity up
to 180 %, pluggable memory chip for
the parameter set
Scalable frequency inverter, V/f con-
trol with feedback, sensorless vector
control, overload capacity up to
200 %, optionally with integrated
safety functions, fieldbus communi-
cation, pluggable memory chip for
the parameter set
Scalable frequency inverter, V/f con-
trol with feedback, sensorless vector
control, point-to-point positioning,
free function block interconnection,
optionally with integrated safety
functions, fieldbus communication,
pluggable memory chip for the pa-
rameter set
Voltage range/power range 1 AC 180 … 264 V: 0.25 … 2.2 kW
3 AC 320 … 550 V: 0.37 … 3.0 kW
1 AC 180 … 264 V: 0.25 … 2.2 kW
3 AC 320 … 550 V: 0.37 … 45 kW
1 AC 180 … 264 V: 0.25 … 2.2 kW
3 AC 320 … 550 V: 0.37 … 45 kW
Approvals CE, UL, GOST-R, RoHS CE, UL, GOST-R, RoHS CE, UL, GOST-R, RoHS
Permissible power systems TN, TT,
RoHS-compliant
TN, TT, IT,
RoHS-compliant
TN, TT, IT,
RoHS-compliant
Switching frequencies 2, 4, 8, 16 kHz 2, 4, 8, 16 kHz 2, 4, 8, 16 kHz
Mechanical design
Built-in unit   
Push-through technique –  (up to 15 kW)  (up to 15 kW)
Cold plate technique –  (up to 22 kW)  (up to 22 kW)
Enclosure IP 20 IP 20 IP 20
Operation in generator mode
Integrated brake resistor  (3 AC 400/500 V)  
External brake transistor  (1 AC 230/240 V) – –
Regenerative – – –
Control types
V/f control   
Vector control (encoderless)   
V/f control –  
VFC eco –  
Synchronous motors (encoderless) –  
Servo control – – 
Drive function
Voltage / frequency control   
Torque control –  
Closed-loop speed control -  
PID controller   
Motion Control – – 
