8
Motion design
8.2
MotionDesigner
258
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.9.4
Distance / angle – basic values
8.2.9.5
Time – basic values
8.2.9.6
Velocity / speed – basic values
8.2.9.7
Time (right) – basic values
Parameter
Description
Distance
Angle
• Translatory motion profile:
• Covered distance when the operation of the element is completed.
• Rotary motion profile:
• Covered angle of rotation when the operation of the element is completed.
Use of the parameter:
"Line" tab: Motion profile ( 250)
"Imported profile" tab ( 254)
Parameter
Description
Time
Time required for the operation of the element.
Use of the parameter:
"Line" tab: Motion profile ( 250)
"Line" tab": Parameter profile ( 251)
"Imported profile" tab ( 254)
Parameter
Description
Velocity
Speed
• Translatory motion profile:
• Max. velocity when the operation of the element is completed.
• Rotary motion profile:
• Max. speed when the operation of the element is completed.
Use of the parameter:
Parameter
Description
Time (right)
Duration of the constant travel after the second acceleration or deceleration.
• The input field is only shown in case of an element for creep speed.
Use of the parameter:
