Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
395
15
Results: comparing, optimising, logging
15.5
Construction data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Solutions
15.5
Construction data
15.5.1
CAD data
geared motor
15.5.2
CAD data
inverter
The different mechanical concepts and drive components can be compared and
optimised with regard to the energy required.
• Click the icon to open the Lenze BlueGreen Solutions dialog box.
If you have defined product features in the Details on Lenze products dimensioning
step, DSD is able to generate the construction data of the geared motor. The
geared motor can be rotated to any position. Use the CAD export button to export
the model to different 2D or 3D formats.
• Click the icon to generate the construction data.
If you have defined product features in the Details on Lenze products dimensioning
step, DSD is able to generate the construction data of the inverter. The inverter
can be rotated to any position. Use the CAD export button to export the model to
different 2D or 3D formats.
• Click the icon to generate the construction data.
