3 User interface
3.1 Control and function elements
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.1.5.2 Sorting and filtering results in selection tables
Sorting results
Sorting by alphanumeric characters is possible. Up to three columns can be included. Table columns
that contain symbols cannot be sorted.

How to sort the results:
1. Click the desired column header .
• The result list is sorted according to the data in the selected table column.
•
Sorting of the data sets in ascending order.
• Sorting of the data sets in descending order.
2. Keep the key pressed and click another column header with the mouse to include an-
other column in the sorting.
Filtering results
• The available filters provide comfortable assistance in selecting specific data sets.

How to filter results:
1. Click the desired button in the header.
• A selection menu opens.
2. Select filter or filter function.
Filter or filter function
Selection menu Description
Display all Reset all filters of the table column.
User-defined When the user-defined filter is selected, a dialog box opens in which three specific filters can
be set.
Identical value
• Select a value to indicate only the data sets with this value.
Value range • Select min. and max. value to indicate only the data sets within
this value range.
Several values • Select several values to indicate only the data sets with these val-
ues.
Alphanumeric char-
acters
The selection menu lists all alphanumeric values of the table column.
• Select a value to indicate only the data sets with this value.
