Page 146: 2 mass of the belt, 7applications

7
Applications
7.12
Belt conveyors for unit loads
146
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.12.1.1
Symbols used
7.12.2
Data for the entry
7.12.2.1
Diameter of the drive roll
7.12.2.2
Mass of the belt
Symbol
Description
Dimension unit
d
Diameter of the drive roll
mm
F
μ
Friction force
N
F
g
Lifting force
N
F
add
Additional force (e. g. backing force)
N
F
aux
Friction force by supporting rolls
N
g
Gravitational acceleration (g = 9.81 m/s
2
)
m/s
2
J
Moment of inertia of driving roller
kgm
2
J
aux
Moment of inertia of supporting rollers
kgm
2
J
sum
Total moment of inertia
kgm
2
l
Conveying length
m
m
L
Mass of the payload
kg
m’
L
Mass of the line load
kg/m
m
Blt
Mass of the belt
kg
m
aux
Total mass of the supporting rolls
kg
m
add
Additional mass (e. g. by deflectors)
kg
M
App
Required torque of the application
Nm
M
sds
Stationary torque
Nm
v
Material speed
m/s
α
Angular acceleration
rad/s
2
β
Angle of tilt
°
μ
Gdn
Coefficient of friction of belt/supporting surface
μ
aux
Coefficient of friction belt/supporting rollers
μ
L
Coefficient of friction of load/belt
Symbol
Description
d
Outside diameter of drive roll
Symbol
Description
m
Blt
Mass of belt
• Value can be entered directly or calculated by the uniform load and conveying length.
"Uniform load mass (material handling technology)" calculator ( 415)
