8 Motion design
8.2 MotionDesigner
260
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.9.13 Right – basic values
8.2.9.14 Controller / brake – basic values
8.2.9.15 Specification – acceleration
8.2.9.16 Left – acceleration
8.2.9.17 Middle – acceleration
8.2.9.18 Right – acceleration
Parameter Description
Right Value when the operation of the element is completed.
 "Line" tab": Parameter profile ( 251)
Parameter Description
Controller locked
Controller released
Control signal for the inverter.
 "Line" tab": Parameter profile ( 251)
Brake activated
Brake released
Control signal for the electromechanical brake.
 "Line" tab": Parameter profile ( 251)
Parameter Description
Specification The following quantities can be selected:
• Max. acceleration.
• Acceleration time:
• Elapsed time until the application has accelerated to setpoint speed.
• Acceleration distance:
• Covered distance until the application has accelerated to setpoint speed.
Use of the parameter:
 "Profile" tab ( 248)
Parameter Description
Left Acceleration from standstill to setpoint speed.
Use of the parameter:
 "Profile" tab ( 248)
Parameter Description
Centre More acceleration or deceleration from a certain speed.
• The input field is only shown in case of an element for creep speed.
Use of the parameter:
 "Profile" tab ( 248)
Parameter Description
Right Deceleration to standstill.
Use of the parameter:
 "Profile" tab ( 248)
