4 Setting up the DSD workplace
4.5 Settings
48
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.5.4 "Motion" register
4.5.5 "Units" tab
Settings Information
Digital resolution motion profile The analog motion profile created in the MotionDesigner is decomposed into
points for further processing in the DSD and for the export into an ASCII file
(digitised).
• Max. resolution [dots]
• Max. number of values the motion profile is decomposed into.
• Max. error rate [%]
• Relative error frequency, with regard to the max. resolution.
Default values, units Default settings for the graphical and numerical creation of motion profiles/
subprofiles.
Flying restart functions Drawing help for the graphical creation of motion profiles/subprofiles. For
simple positioning of drawn elements.
Settings Information
Unit systems Definition of unit systems that are to be available in the input masks.
• You can both select the SI unit system or the Imperial unit system.
Preferred unit system Application of the unit system: Imperial or Metric with regard to inputs and
outputs.
Preferred units Definition of the units for frequently used physical quantities.
