8 Motion design
8.2 MotionDesigner
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.9 Parameter area: Data for the entry
The following chapters describe data that can be entered or selected in the parameter area.
8.2.9.1 – Type
8.2.9.2 Specification – Type
8.2.9.3 Specification – basic values
Parameter Description
Name of the parameter that is selected in the object area.
• Read only.
 "Line" tab": Parameter profile ( 251)
 Object properties ( 231)
Parameter Description
Specification Standard value with which the parameter is automatically created.
• The entry of more line elements creates an individual parameter profile.
• The "brake" and "controller inhibit" parameters do not have a default value as these con-
trol signals can only have the states 1 or 0.
 "Line" tab": Parameter profile ( 251)
 Object properties ( 231)
Parameter Description
Specification Selection of the quantities to be entered.
• Translatory motion profile:
• Velocity / time
• Distance/time
• Distance / velocity
• Rotary motion profile:
• Speed / time
• Angle / time
• Angle / velocity
Use of the parameter:
 "Profile" tab ( 248)
 "Line" tab: Motion profile ( 250)
 "S-edge" tab ( 253)
 "Imported profile" tab ( 254)
• Positioning
Use of the parameter:
 Positioning ( 255)
