Alternatively the travelling resistance F’ can be related to the mass [N/t]:
[7-70] Equation 8: Travelling resistance
[7-71] Equation 9: Friction torque
Torque of the application
[7-72] Equation 10: Torque of the application
Spinning
In order to prevent the drive wheels from spinning, a maximum permissible acceleration can be de-
termined. In the calculation the wheel load, the angle of tilt, the total mass, and the friction coeffi-
cient and a possible counterforce (F
vs
) are taken into consideration.
[7-73] Equation 11: Permissible spinning acceleration
Driving against a limit stop
The maximum torque during driving against a limit stop depends on the friction force and the di-
ameter of the driving wheels. After the friction force has been overcome, the torque is reduced by
spinning wheels.
[7-74] Equation 12: Torque at the gearbox output during driving against a limit stop
Tip!
Further equations to complete the calculations required for an application can be found in
