18 Drive dimensioning messages
18.3 Additional drive element
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
18.3 Additional drive element
18.3.1 Rated torque loss is exceeded
18.3.2 Min. ratio (K) is higher than max. ratio (K)
Note!
The constant torque loss at the output end of the additional drive component is xxx. Thus the rated torque
loss of yyy is exceeded.
Cause Effects Possible remedies
The general ratio is characterised by
the "permissible torque". The effi-
ciency in this operating point defines
the max. constant loss of yyy. Accord-
ing to this definition, the constant
torque loss exceeds the limit value.
 Constant torque loss ( 345)
The entered values are not consist-
ent. The calculation leads to wrong
results.
Correct the entries.
Stop!
The ratio range of the additional drive element has not been entered correctly.
The minimum value is greater than the maximum value.
With these values, dimensioning is not possible.
Cause Effects Possible remedies
The entered min. ratio (i
min,K
) of the
"additional drive element" is higher
than the entered max. ratio (i
max,K
).
Drive dimensioning cannot be car-
ried out.
Exchange the entered values for i
m-
in,K
and i
max,K
.
