2 About this documentation
2.2 Conventions used
16
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
2.2 Conventions used
This documentation uses the following conventions to distinguish the following types of informa-
tion:
Type of information Marking Examples/notes
Spelling of numbers
Decimal separator
Point The decimal point is generally used.
For example: 1234.56
Text
Version info
Blue text colour Information that is only valid for or as from a certain soft-
ware version of the controller is marked accordingly in this
documentation.
Example: The function extension is available from software
version V3.0 or higher!
Program name » « The Lenze PC software »PLC Designer«...
Window area Italics The Message window... / The Options dialog box...
Variable identifiers By setting bEnable to TRUE...
Control element Bold The OKbutton... / The Copy command ... / The Properties
tab... / The Name input field ...
Sequence of menu com-
mands
If several commands in succession are required to carry out a
function, the individual commands are separated by an ar-
row: select the command File  Open to...
Keyboard command By , you call up the online help.
If a keyboard combination is required for a command, a "+" is
placed between the keyboard identifiers: by +...
Program code
Courier
IF var1 < var2 THEN
a = a + 1
END IF Keyword
Courier bold
Hyperlink underlined Optically highlighted reference to another topic which is ac-
tivated via mouse-click in this online documentation.
Icons
Page reference
( 16) Optically highlighted reference to another page which is ac-
tivated via mouse-click in this online documentation.
Step-by-step instruction  Step-by-step instructions are indicated by a pictograph.
