3 User interface
3.1 Control and function elements
20
Lenze · Drive Solution Designer · Manual · DMS 4.2 EN · 12/2013 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.1.1.3 View
3.1.1.4 Extras
Menu command Function
Notes • Note recording current dimensioning step
• Display or write a comment on the current dimensioning step.
• All notes
• Display, print or deletion of all comments that were created for the
project.
 Notes ( 37)
Messages Shows all warnings, notes and tips for the current drive dimensioning.
 Drive dimensioning messages ( 441)
Dimensioning report Create and display Protocol.
• The dimensioning protocol that is generated can be printed or opened in
Microsoft Word.
• The completeness of the report depends on the progress of the dimen-
sioning. If the dimensioning report is opened early, some components
possibly are not displayed.
• At the end of the drive dimensioning the DSD offers different possibilities
of presenting the results.
 Protocols ( 391)
Project comparison Compare projects among each other.
• If several projects are open at the same time, they can be compared with
respect to the application and the utilisation of the components.
 Protocols ( 391)
Product features for DSC / SAP Shows product features of the components which are required for the pur-
chase order with »Drive Solution Catalogue« (DSC). DSC is the electronic cat-
alogue on the Lenze web page.
Menu command Function
User-defined defaults Display/definition of user-defined specifications.
• User-defined specifications can be established for specific parameters re-
quiring manual entries or featuring an option.
Select language Change the language of the user interface.
• German, English (British), Czech, Danish, English (American), Spanish,
French, Italian, Dutch, Russian, Swedish, Chinese (simplified) and Chinese
(traditional) are provided.
Settings  Settings ( 46)
