8 Motion design
8.2 MotionDesigner
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.2.6.3 Setting XY axes
Changing the units of the axes
Shifting the zero point of the XY axes
Scaling the XY axes
• Click the selection field using the mouse and select the desired unit.
• Values that have already been entered are converted to the newly se-
lected unit.
• Units can be defined globally in the ExtrasSettings menu in the "Mo-
tion" register . ( 48)
1. Move the mouse over the desired axis until the form of the mouse point-
er changes.
2. Press left mouse button and shift the zero point of the axis.
3. Release the mouse button at the desired position.
1. Keep the key pressed and move the mouse of the desired axis until
the form of the mouse pointer changes.
2. Press left mouse button and shift the mouse towards the shown arrows.
3. Release the mouse button at the desired scaling.
