AT Commands Reference Guide
80000ST10025a Rev. 5 - 09/07/08
Reproduction forbidden without Telit Communications S.p.A. written authorization - All Rights Reserved page 268 of 434
#VAUX- Auxiliary Voltage Output Control SELINT 2
enabled or not, in the format:
#VAUX:
AT#VAUX=? Test command reports the supported range of values for parameters ,
.
3.5.7.1.35 Auxiliary Voltage Output Save - #VAUXSAV
#VAUXSAV - Auxiliary Voltage Output Save SELINT 2
AT#VAUXSAV Execution command saves the actual state of #VAUX pin to NVM. The state
will be reload at power-up.
AT#VAUXSAV=? Test command returns the OK result code.
3.5.7.1.36 V24 Output Pins Configuration - #V24CFG
#V24CFG - V24 Output Pins Configuration SELINT 2
AT#V24CFG=,
Set command sets the AT commands serial port interface output pins mode.
Parameters:
- AT commands serial port interface hardware pin:
0 - DCD (Data Carrier Detect)
1 - CTS (Clear To Send)
2 - RI (Ring Indicator)
3 - DSR (Data Set Ready)
- AT commands serial port interface hardware pins mode:
0 - AT commands serial port mode: output pins are controlled by serial port
device driver. (default)
1 - GPIO mode: output pins are directly controlled by #V24 command only.
AT#V24CFG? Read command returns actual mode for all the pins (either output and
input) in the format:
#V24CFG: ,[
#V24CFG: ,[...]]
Where:
n> - AT command serial port interface HW pin
n> - AT commands serial port interface hardware pin mode
AT#V24CFG=? Test command reports supported range of values for parameters and
.
3.5.7.1.37 V24 Output Pins Control - #V24
#V24 - V24 Output Pins Control SELINT 2
AT#V24=
[,] Set command sets the AT commands serial port interface output pins state.
Parameters:
