Rainbow Electronics GPS receiver

High Accuracy
Extended Temperature
Range -40 °C to +85 °C
Low Power
Consumption
Anti-Jamming
RoHS Compliant
USB 2.0 full speed
compliant interface
Super sensitivity
-165dBm tracking
The GPS module L10 brings the high performance of
the MTK positioning engine to the industrial standard.
The L10 supports 210 PRN channels. With 66 search
channels and 22 simultaneous tracking channels, it
acquires and tracks satellites in the shortest time even
at indoor signal level. This versatile, stand-alone
receiver combines an extensive array of features with
flexible connectivity options. Their ease of integration
results in fast time-to-market in a wide range of
automotive, consumer and industrial applications.
L10
Compact GPS Module with Super
Sensitivity
Wireless makes smarter
SMD Type
Advantages
●210 PRN channels, with 66 search channels and 22
simultaneous tracking channels
●-165dBm tracking sensitivity
●Highest autonomous mode acquisition sensitivity, -148dBm
●Low tracking power consumption, 38mA (passive antenna)
●Full ESD protection on all pins
●Embedded with one 4Mbits flash memory
●Superior anti-jamming design for best integration with other
wireless application, such as WiFi, WiMax, CDMA and GSM
●Multi-path detection and correction for accurate navigation in
harsh urban canyon
●Up to 5Hz update rate
●USB 2.0 full speed compliant interface
