AT Commands Reference Guide

80000ST10025a Rev. 5 - 09/07/08

page 262 of 434

#DVI - Digital Voiceband Interface

SELINT 2

1 - DVI port 1 will be used (factory default)
2 - DVI port 2 will be used

0 - DVI slave
1 - DVI master (factory default)

Note: setting =0 has full effect only if =1

AT#DVI?

Read command reports last setting, in the format:

#DVI: ,,

AT#DVI=?

Test command reports the range of supported values for parameters
, and

Example

AT#DVI=2,1,1

OK

Both analog and DVI activated for audio. DVI is
configured as master providing on DVI Port #1

3.5.7.1.31 SMS Ring Indicator - #E2SMSRI

#E2SMSRI - SMS Ring Indicator

SELINT 0 / 1

AT#E2SMSRI[=
[]]

Set command enables/disables the Ring Indicator pin response to an
incoming SMS message. If enabled, a negative going pulse is generated on
receipt of an incoming SMS message. The duration of this pulse is
determined by the value of .

Parameter:
- RI enabling
0 - disables RI pin response for incoming SMS messages (factory default)
50..1150 - enables RI pin response for incoming SMS messages. The

value of is the duration in ms of the pulse generated on receipt of
an incoming SM.

Note: if +CNMI=3,1 command is issued and the module is in a GPRS
connection, a 100 ms break signal is sent and a 1 sec. pulse is generated
on RI pin, no matter if the RI pin response is either enabled or not.

Note: issuing AT#E2SMSRI is the same as issuing the Read
command.

Note: issuing AT#E2SMSRI= returns the OK result code.

AT#E2SMSRI?

Read command reports the duration in ms of the pulse generated on
receipt of an incoming SM, in the format:

#E2SMSRI:
