Chapter 4: Configuring the AT-CV5M02 Management Card
98
Viewing the Event Log
For background information, refer to “Event Log” on page 23.
Menus
To display the event log from the menus:
1. From the Main Menu, select Administration. The Administration
Menu is shown in Figure 28.
Figure 28. Administration Menu
2. From the Administration Menu, select Event Log to display the Event
Log Menu window shown in Figure 29.
Figure 29. Event Log Menu
3. From the Event Log Menu, select Display Event Log. An example of
the event log is shown in Figure 30. The messages are displayed from
oldest to newest.
Administration Menu
Converteon
Ping a Remote System
Syslog Server Address:
Null (not configured)
Syslog Facility Code: 1
Event Log
Activity Monitor
Start Activity Monitor
> Stop Activity Monitor
Diagnostics
Reset Chassis and Restart Line Cards
Return to Main Menu...
Event Log Menu
Converteon
Display Event Log
Clear Event Log
Return to Administration Menu ...
