AT-S73 and AT-S99 Management Software User’s Guide
177
FIBER PORT or COPPER PORT
ST This column displays the states of the twisted pair ports on the
remote line cards. The possible states are:
ˆ * - The twisted pair port has establish a link to a network device.
ˆ o - The twisted pair port has not establish a link to a network
device.
This column is omitted for the fiber optic port because remote peer
management will not work without a connection between the fiber
optic ports of the local and remote line cards.
SP This column displays the speeds of the remote ports. The possible
speeds are:
ˆ 10 - 10 Mbps
ˆ 100 - 100 Mbps
ˆ 1G - 1 Gbps
FC This column displays the status of flow control on the ports of the
remote AT-CM Line Cards. The possible states are:
ˆ Y - Flow control is enabled on the port.
ˆ N - Flow control is disabled on the port.
IngRL This column displays the settings of the ingress rate limiting filters
on the ports on the remote AT-CM Line Cards. The value “0” means
rate limiting has not been set on the port. This is the default setting.
EgrRL This column displays the settings of the egress rate limiting filters on
the ports on the AT-CM Line Cards. The value “0” means rate
limiting has not been set on the port. This is the default setting.
OAM This column displays the status of the OAM clients on the remote
AT-CM Line Cards. The following OAM client information is
displayed:
Table 20. Remote Module Status and Configuration Menu
Column Description
*00
C
B
A
