AT-S73 and AT-S99 Management Software User’s Guide
167
Displaying the MAC Addresses and Serial Numbers
This section has procedures that explain how to display the MAC
addresses and serial numbers of the cards in the chassis. You may be
asked to provide this information in the event you contact Allied Telesis for
technical assistance.
Menus To view the information from the menus:
1. From the Main Menu, select Administration. The Administration
Menu is shown in Figure 28 on page 98.
2. From the Administration Menu, select Diagnostics to display the
Diagnostic Menu shown in Figure 45 on page 121.
3. From the Diagnostics Menu, select Line Card Information. An
example of the Line Card Module Information window is shown in
Figure 71.
Figure 71. Line Card Module Information Window
Line Card Module Information
Converteon
Module MAC Address Serial Number
1: AT-CV5M02 -- A02803L05060001S C
2: AT-CM202 00:0C:46:CE:D9:60 A03572L061100040 B
3: AT-CM202 00:0C:46:CE:D9:72 A03572L061100170 B
4: AT-CM202 00:0C:46:CE:D9:02 A03572L061100014 B
5: AT-CM202 00:0C:46:CE:DA:12 A03572L061100111 B
6: AT-CM212A/1 00:15:77:52:5C:6F A03578G071400012 A
7: AT-CM212A/1 00:15:77:52:5C:A1 A03578G071400225 A
8: AT-CM212A/1 FF:FF:FF:FF:FF:FF A03713G070500081 B
9: AT-CM212A/1 FF:FF:FF:FF:FF:FF A03713G070500120 B
10:AT-CV102 FF:FF:FF:FF:FF:FF A03713G070500214 B
11: AT-CV102 FF:FF:FF:FF:FF:FF A03713G070500012 B
12: AT-CV102 FF:FF:FF:FF:FF:FF A03713G070500087 B
13: AT-CV102 FF:FF:FF:FF:FF:FF A03713G070500055 B
14: AT-CV102 FF:FF:FF:FF:FF:FF A02765G070500146 D
15: Mezzanine
16:(Not Inserted)
-- --
17:(Not Inserted) -- --
18:(Not Inserted) -- --
Hit any key to continue ...
